Superior Simple Stable Smart
An entry-level foot treatment device enhances the simplicity and efficacy of foot care, offering streamlined therapeutic interventions with advanced capabilities.
Detailed Protocols Preset
30+ presets therapeutic regime of podiatry provid- ed, as well as the user friendly interface design, all give the proper suggestion and direction to surgeons, which make the users even those who are fresh hand on laser devices can begin the procedures easily.
Patented Control System
Original Advanced Laser Stabilization System solves the problem of highly heat generation of laser module, which guarantees the ultimate stability and quietness of M3 in the case of long-time and high-power output
Illuminate Your Path to Foot Wellness: Experience Laser Treatment
Advanced laser therapy harnesses the power of light to safely and painlessly alleviate pain, inflammation, and swelling. By emitting targeted wavelengths, the laser accelerates healing processes while effectively reducing discomfort, making it a non-invasive and highly effective treatment option.
HOW 980NM LASER WORK ON NAIL?
980m wavelength laser has demonstrated superior results in nail fungus removal, showing safety and efficacy. Its excellent feature of deep penetration providesa good effective treatment through the nail, with less impacting surrounding tissues. With the best performance in comprehensive property of absorption by tissue element, 980m can treat kinds of podiatry diseases with different hand pieces which present no side effects and completely safe with no pain.
PODIATRY APPLICATION:
Certainly! Laser therapy is applied effectively in various podiatric treatments:
-
Matricectomy:
Precise laser removal of nail matrix to treat ingrown toenails.
-
Vascular Lesions:
Targeted laser treatment for vascular conditions like spider veins and telangiectasia.
-
Corns/Callus:
Laser therapy to reduce and manage thickened skin on the feet.
-
Nail Fungus:
Laser treatment for onychomycosis, promoting healthier nail growth.
-
Warts Removal:
Laser therapy to eliminate warts on the feet.
-
Tissue Inflammation:
Laser application to reduce inflammation in foot tissues, aiding in pain relief and healing.
The advantage of laser treatment ?
The advantages of laser therapy for treating foot conditions lie in its non-invasive nature and high efficacy. It precisely targets pain, inflammation, and swelling, promoting tissue repair and regeneration without the need for drugs or surgery. Laser treatment is safe, painless, and minimizes discomfort during and after the procedure, resulting in quicker recovery times and allowing patients to return to normal activities promptly.
Technical Specification
Wavelength: | 980nm |
Power: | 15W |
Aiming Beam: | 650nm < 5mW, adjustable density |
Fiber Connection: | 400pm and 600pm Fiber with SMA905 connector |
Operating Modes: | Continuous (CW) / Pulse / Single Pulse |
Power Supply: | 18VDC, 5A |
Dimensions(L*W*H): | 210mm*165mm*160mm |
WeightPolymer: | Composite materials |
Display: | 7-inch HD Vivid Touch-Screen/Smart OS |
The medical laser device complies with the following standards
IEC 60601-1:2020 | ISO 14971:2019 |
IEC 60601-1-2:2020 | ISO 24971:2020 |
IEC 60601-2-22:2019 | ISO 10993-1:2018 |
IEC 60825-1:2014 | ISO 15223-1:2021 |
IEC 62304:2015 | ISO 14971:2019 |
IEC 62366-1:2020 |
Medical-Grade Instruments and Accessories
Handpieces
Surgical Zoom Handpiece
Minimum spot Variable-zoom High efficiency transmission For contactless applications:Spider Vein/Nail fungus/Vascular Dermatosis
LEARN MOREFocusing Handpiece
Fiber 300um, 400um SMA905 connector Magnification confocal: 1:1 Spot diameter: 1mm, 2mm and 3mm For non-contact treatment:Spider VeinNail fungusVascular Dermatosis
LEARN MOREMedical Fibers and Tips
Bare fiber
Bare Fibers(200μm) Length: 3m;Bare Fibers(300μm) Length: 3m;Bare Fibers(400μm) Length: 3m
LEARN MOREAccessories
Professional Laser Safety Glasses - Made in Germany (Recommend)
Essential protective gear for laser operations, designed to absorb or reflect specific laser wavelengths effectively, safeguarding the eyes from harm. Compliant with the European Committee for Standardization (CEN) EN 207 standard.
LEARN MOREMultilingual instruction manual
A multilingual instruction manual can enhance user experience, meet regulatory requirements, boost brand image, and improve customer support efficiency.
LEARN MOREMedical-grade Adapter
Compliant with IEC 60601-1, an international standard regarding the safety and performance of medical electrical equipment, ensuring enhanced safety and reliability.
LEARN MOREPacking Box
Packing Box is specifically designed to provide secure and protective storage for diode lasers.
LEARN MOREBare fiber holder
Facilitating the placement and stretching of optical fibers during the laser operation process.
LEARN MORELaser Safety goggles
Essential protective equipment for laser operations, capable of effectively absorbing or reflecting specific wavelengths of laser light to prevent eye injury.
LEARN MOREMedical-grade Plug
Compliant with IEC 60601-1, an international standard regarding the safety and performance of medical electrical equipment, ensuring enhanced safety and reliability.
LEARN MOREBluetooth Medical-grade Foot Pedal (Optional)
Foot pedal, tested for 500,000 cycles, with accompanying test reports, supporting both wired and wireless Bluetooth connectivity.(Optional)
LEARN MOREMedical-grade Foot Pedal (Optional)
Waterproof foot pedal, passing the waterproof test, with a 500,000 times usage test report.(Optional)
LEARN MORE
